TL072CDT SMD IC OpAmp แบบ SMD 8 ขา ยี่ห้อ ST

Manufacturer: STMicroelectronics Product Category: Operational Amplifiers - Op Amps Mounting Style: SMD/SMT Package / Case: SO-8 Number of Channels: 2 Channel Supply Voltage - Max: 36 V, +/- 18 V GBP - Gain Bandwidth Product: 4 MHz Output Current per Channel: 40 mA SR - Slew Rate: 16 V/us Vos - Input Offset Voltage: 10 mV Supply Voltage - Min: 6 V, +/- 3 V Minimum Operating Temperature: 0 C Maximum Operating Temperature: + 70 C Ib - Input Bias Current: 200 pA Operating Supply Current: 2.5 mA Shutdown: No Shutdown CMRR - Common Mode Rejection Ratio: 70 dB en - Input Voltage Noise Density: 15 nV/sqrt Hz Series: TL072 Packaging: Cut Tape Packaging: MouseReel Packaging: Reel Amplifier Type: Low Noise Amplifier Height: 1.65 mm Length: 5 mm Product: Operational Amplifiers Supply Type: Single, Dual Technology: BiFET Width: 4 mm Brand: STMicroelectronics Dual Supply Voltage: +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V Maximum Dual Supply Voltage: +/- 18 V Minimum Dual Supply Voltage: +/- 3 V Operating Supply Voltage: 6 V to 36 V, +/- 3 V to +/- 18 V Pd - Power Dissipation: 680 mW Product Type: Op Amps - Operational Amplifiers PSRR - Power Supply Rejection Ratio: 70 dB Subcategory: Amplifier ICs Voltage Gain dB: 106.02 dB
