MAINBOARD (เมนบอร์ด) ASROCK B760M PRO RS/D4 WIFI (DDR4) (SOCKET LGA 1700) (MICRO-ATX)

Model BrandAsrock ModelB760M Pro RS/D4 WiFi CPU Socket1700 (12th Gen - Alder Lake) , 1700 (13th Gen - Raptor Lake) Wattage150W ChipsetIntel B760 SeriesCore i3 , Core i5 , Core i7 , Core i9 , Pentium Memory Slot4 Memory TypeDDR4 Max. Capacity128 GB Speed2400 , 2666 , 2933 , 3200 , 4000 (OC) , 4266 (OC) , 4400 (OC) , 5333 (OC) Graphic & Audio GraphicIntegrated Graphics Processor (Depends on CPU) AudioRealtek ALC897 7.1 CH HD Audio Storage SATA 2- Port SATA 34 Port RAIDRAID 0, 1, 5, 10 for SATA Storage M.22 x M.2 Slot(s) — CPU: • 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode — Chipset: • 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode Port Expansion Slots DetailsSupports AMD CrossFire Slot1 x PCIe 4.0 x1 Slot , 2 x PCIe 4.0 x16 Slot Network LANDragon RTL8125BG LAN Speed10/100/1000/2500 Mbps WirelessWi-Fi 6E (802.11ax) Bluetooth 5.3 Back Panel I/O Ports USB 2.02 Port USB 3.0- Port USB 3.1- Port Serial- Port USB 3.21 x USB 3.2 Gen1 Type-C 3 x USB 3.2 Gen1 Type-A Port D-Sub (VGA)- Port DVI- Port HDMI1 Port DisplayPort1 Port Audio3 Port PS/21 Port Additional2 x Antenna Ports LAN1 Port Form Factor Form FactorMicro-ATX Power Connector24 + 8 Pin Dimension24.40 x 24.40 cm Warranty การรับประกัน3 Years
