TP-Link TL-SG108E (TL-SG108E) 8G Easy Smart Switch

HARDWARE FEATURES Standards and Protocols • IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p Interface • 8 10/100/1000 Mbps RJ45 Ports • AUTO Negotiation/AUTO MDI/MDIX Network Media • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) Fan Quantity • Fanless Power Supply • External Power Adapter(Output: 5 VDC/ 0.6 A) Dimensions ( W x D x H ) • 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm) Max Power Consumption • 3.68 W (220 V/ 50 Hz) Max Heat Dissipation • 12.55 BTU/h PERFORMANCE Switching Capacity • 16 Gbps Packet Forwarding Rate • 11.9 Mpps MAC Address Table • 4 K Packet Buffer Memory • 1.5 Mb Jumbo Frame • 16 KB SOFTWARE FEATURES Quality of Service • Support Port-based/802.1p/DSCP priority • Support 4 priority queues • Rate Limit • Storm Control L2 Features • IGMP Snooping V1/V2/V3 • Static Link Aggregation • Port Mirroring • Cable Diagnostics • Loop Prevention VLAN • Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs) MTU/Port/Tag VLAN Transmission Method • Store-And-Forward OTHERS Certification • FCC, CE, RoHS Package Contents • TL-SG108E • Power Adapter • Installation Guide • Rubber Feet System Requirements • Microsoft® Windows® for running Utility Environment • Operating Temperature: 0℃~40℃ (32℉~104℉) • Storage Temperature: -40℃~70℃ (-40℉~158℉) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing
