ชุดหัวเข็ม Ortofon - 2M Red Moving Magnet Cartridge สำหรับเครื่องเล่นแผ่นเสียง Turntable

ชุดหัวเข็ม Cartridge รุ่น 2M Red แบรนด์ Ortofon สำหรับเครื่องเล่นแผ่นเสียง รายละเอียด : - Output voltage at 1000 Hz, 5cm/sec. - 5.5 mV - Channel balance at 1 kHz - 1.5 dB - Channel separation at 1 kHz - 22 dB - Channel separation at 15 kHz - 15 dB - Frequency range at - 3dB - 20-22.000 Hz - Frequency response - 20-20.000 Hz + 3 / - 1 dB - Tracking ability at 315Hz at recommended tracking force - 70 µm - Compliance, dynamic, lateral - 20 µm/mN - Stylus type - Elliptical - Stylus tip radius - r/R 8/18 µm - Tracking force range - 1.6-2.0 g (16-20 mN) - Tracking force, recommended - 1.8 g (18 mN) - Tracking angle - 20° - Internal impedance, DC resistance - 1.3 kOhm - Internal inductance - 700 mH - Recommended load resistance - 47 kOhm - Recommended load capacitance - 150-300 pF - Cartridge colour, body/stylus - Black/Red - Cartridge weight - 7.2 g ในกล่องมี ของแถมดังนี้ ; - Stylus brush x 1 ชิ้น - Screwdriver x 1 ชิ้น - Screw M2,5 x 5 x 2 ชิ้น - Screw M2,5 x 7 x 2 ชิ้น สินค้าผลิต และ นำเข้าจากประเทศ Denmark Features The 2M Red features a tipped Elliptical diamond and split pole pins with a copper wire. An improved engine provides an increased output of 5.5 mV and an optimized sound reproduction and a high level of sonic accuracy. The cartridge body is manufactured from Hopelex, which ensures high rigidity while eliminating unwanted resonances. We have optimized the design for ease of mounting the cartridge, and the weight and size to fit the most common turntables on the market today. The 2M Series provides excellent compatibility when used in an assortment of playback systems and with a wide variety of phono preamps. 2M Red is an all-purpose cartridge that delivers open, dynamic sound with a slight touch of warmth.
