P1-xx/EA/SVB - สวิตช์ตัดวงจรแบบบิด เปิด-ปิด, P1, 25 A, 32 A, flush mounting, 3 pole, Main switch

Product : P1-25/EA/SVB, P1-32/EA/SVB Product weight : 0.192 kilogram Product Tradename : P1 Product Type : Main switch Catalog Notes : Rated Short-time Withstand Current (Icw) for a time of 1 second Features : Version as emergency stop installation, Version as main switch, Version as maintenance-/service switch Fitted with : Red rotary handle and yellow locking ring Number of poles : 3 Degree of protection (front side) : IP65 Rated impulse withstand voltage (Uimp) : 6000 V AC Safe isolation : 440 V AC, Between the contacts, According to EN 61140 Screw size : M4, Terminal screw
