MSI MONITOR (จอมอนิเตอร์)PRO MAX 241PHW E14 | 271QPHW E14 | 271PHW E14

PRO MAX 241PHW E14 PANEL SIZE 23.8" PANEL RESOLUTION 1920 x 1080 (FHD) REFRESH RATE 144Hz RESPONSE TIME 1ms (MPRT) / 4ms (GTG) PANEL TYPE IPS BRIGHTNESS (NITS) 300 cd/m2 VIEWING ANGLE 178°(H) / 178°(V) ASPECT RATIO 16:9 CONTRAST RATIO 1500:1 Signal Frequency 54~169.78 KHz(H) / 48~144 Hz(V) ADOBE RGB / DCI-P3 / SRGB 93% / 96% / 122% (CIE1976) ACTIVE DISPLAY AREA (MM) 527.04(H) x 296.46(V) PIXEL PITCH (H X V) 0.2745(H) x 0.2745(V) SURFACE TREATMENT Anti-Glare with Circular Polarization DISPLAY COLORS 16.7M COLOR BIT 8 bits (6 bits + FRC) VIDEO PORTS HDR SUPPORT HDR Ready 1x HDMI™ 2.0b (FHD@144Hz) 1x DisplayPort 1.2a 1x Type-C (DP alt.) w/ 65W PD USB Ports 2x USB 5Gbps Type-A 1x USB 5Gbps Type-B AUDIO PORTS 1x Headphone-out KENSINGTON LOCK Yes SPEAKER 2x 3W VESA MOUNTING 75 x 75 mm POWER TYPE Internal Power Board POWER INPUT 100~240V, 50/60Hz DYNAMIC REFRESH RATE TECHNOLOGY Adaptive-Sync Dimension with Stand (W x D x H) 541.93 x 200.81 x 381.11mm(21.34 x 7.91 x 15.00 inch) Dimension without Stand (W x D x H) 541.93 x 65.44 x 322.28 mm(21.34 x 2.58 x 12.69 inch) CARTON DIMENSION (W X D X H) 814 x 149 x 410 mm(32.05 x 5.87 x 16.14 inch) WEIGHT (NW / GW) 5.35 kg (11.79 lbs) / 8 kg (17.64 lbs) ACCESSORIES 1x HDMI™ Cable (2.0b), 1x Type-C Cable (3.2 Gen 1), 1x USB Type-B to A Cable (3.2 Gen 1), 1x Power Cord, 1x Quick Guide, 4x VESA Wall Mount Screw, Color Report, 1x Cable Clip *Note HDMI™: 1920 x 1080 (Up to 144Hz) DisplayPort: 1920 x 1080 (Up to 144Hz) Type-C: 1920 x 1080 (Up to 144Hz) Delta-E (△E) ≤ 2 Support: HDMI™ CEC / MSI Power Link, KVM 1.0, FW Update; Non-Support: PIP/PBP ------------------------------------------------------------------------------------------------------------------- PRO MAX 271QPHW E14 PANEL SIZE 27" PANEL RESOLUTION 2560 x 1440 (WQHD) REFRESH RATE 144Hz RESPONSE TIME 1ms (MPRT) / 4ms (GTG) PANEL TYPE IPS Signal Frequency 72~216 KHz(H) / 48-144 Hz(V) ADOBE RGB / DCI-P3 / SRGB 87% / 93% / 121% (CIE1976) ASPECT RATIO 16:9 HDR SUPPORT HDR Ready USB Ports 2x USB 5Gbps Type-A 1x USB 5Gbps Type-B AUDIO PORTS 1x Headphone-out SPEAKER 3W x2 BRIGHTNESS (NITS) 300 cd/m2 POWER INPUT 100~240V, 50/60Hz DYNAMIC REFRESH RATE TECHNOLOGY Adaptive-Sync Dimension with Stand (W x D x H) 613.49 x 200.81 x 401.72 mm(24.15 x 7.91 x 15.82 inch) Dimension without Stand (W x D x H) 613.49 x 63.81 x 362.45 mm(24.15 x 2.51 x 14.27 inch) CARTON DIMENSION (W X D X H) 613.49 x 63.81 x 362.45 mm(24.15 x 2.51 x 14.27 inch) ACCESSORIES 1x HDMI Cable (2.0b), 1x Type-C Cable (3.2 Gen 1), 1x USB Type-B to A Cable (3.2 Gen 1), 1x Power Cord, 1x Quick Guide, 4x VESA Wall Mount Screw, Color Report PIXEL PITCH (H X V) 0.2331(H) x 0.2331V) SURFACE TREATMENT Anti-glare DISPLAY COLORS 16.7M COLOR BIT 8 bits (6 bits + FRC) VIDEO PORTS 2x HDMI™ 2.0b (WQHD@144Hz) 1x DisplayPort 1.2a 1x Type-C (DP alt.) w/ 65W PD KENSINGTON LOCK Yes VESA MOUNTING 75 x 75 mm NOTE HDMI™: 2560 x 1440 (Up to 144Hz) DisplayPort: 2560 x 1440 (Up to 144Hz) Type-C: 2560 x 1440 (Up to 144Hz) Delta-E (△E) ≤ 2 Support: HDMI CEC/ MSI Power Link, KVM 1.0, FW Update, PI App, M-Mate App; Non-Support: PIP/PBP warranty 3 years ------------------------------------------------------------------------------------------------------------------- PRO MAX 271PHW E14 PANEL SIZE 27" PANEL RESOLUTION 1920 x 1080 (FHD) REFRESH RATE 144Hz RESPONSE TIME 1ms (MPRT) / 4ms (GTG) PANEL TYPE IPS BRIGHTNESS (NITS) 250 cd/m2 VIEWING ANGLE 178°(H) / 178°(V) ASPECT RATIO 16:9 CONTRAST RATIO 1000:1 Signal Frequency 52.8~240.8 KHz(H) / 48~200 Hz(V) ADOBE RGB / DCI-P3 / SRGB 86% / 86% / 111% ACTIVE DISPLAY AREA (MM) 527.04(H) x 296.46(V) PIXEL PITCH (H X V) 0.2745(H) x 0.2745(V) SURFACE TREATMENT Anti-glare DISPLAY COLORS 16.7M, COLOR BIT 8 bits (6 bits + FRC) HDR Ready VIDEO PORTS 1x HDMI™ 2.0b (FHD@144Hz) 1x DisplayPort 1.2a 1x Type-C (DP alt.) w/ 65W PD USB Ports 2x USB 5Gbps Type-A 1x USB 5Gbps Type-B AUDIO PORTS 1x Headphone-out SPEAKER 3W x2 VESA MOUNTING 75 x 75 mm POWER TYPE Internal Power Board warranty 3 years -------------------------------------------------------------------------------------------------------------------
