TADA 234XL crossover ครอสโอเวอร์อนาล็อก เครื่องแยกสัญญาณเสียง234XL Electronic crossover TADA รุ่น 234 XL ครอส2ทาง 234...

TADA TADA 234XL crossover SPECIFICATIONS INPUT Connectors: 1/4" TRS or XLR Type: Electronically balanced/unbalanced, RF filtered Impedance: Balanced > 50kQ, unbalanced > 25k Max Input Level: CMRR: +22 dBu typical, balanced or unbalanced CMRR: >40 dB, typically > 55 dB at 1 kHz OUTPUT Connectors: 1/4" TRS Type: Impedance-balanced/unbalanced, RF filtered Impedance: Balanced 2009, unbalanced 100 Max Output Level: >+21 dBu balanced/unbalanced into 2 k or greater OUTPUT Connectors: XLR Type: Electronically-balanced/unbalanced, RF filtered Impedance: Balance 600, unbalance 30Ω Max Output Level: >+20 dBu balanced/unbalanced into 600 or greater PERFORMANCE: Bandwidth: 20 Hz to 20 kHz +0/-0.5 dB Frequency Response:<3 hz to> 90 kHz, +0/-3 dB Signal-to-Noise: Ref: +4 dBu, 22 kHz measurement bandwidth Stereo Mode: Mono Mode: >94 dB >94 dB Low-Mid Output: >94 dB Mid Output: >93 dB High-Mid Output: >92 dB High Output: >90 dB >88 dB >94 dB >94 dB Mid Output: >93 dB High Output: >91 dB >91 db Dynamic Range: >106 dB, unweighted, any output THD+Noise: <0.004% at +4 dBu, 1kHz <0.04% at +20 dBu, 1 kHz InterChanel Crosstalk: <-80 dB, 20 Hz to 20 kHz FUNCTION SWITCHES: Front Panel: Low Cut Activates 40 Hz Butterworth, 12 dB/octave high-pass filter, one switch per channel. Phase Invert: Inverts the phase at the output, one switch per output. Rear Panel: x10: Multiplies crossover frequency range by 10, one switch per channel. Mode: LF Sum: Selects stereo/mono and 2/3/4-way operation. Selects normal (stereo) or mono-summed low frequency operation.
