220V single-phase input single-phase output 2.2KW frequency conversion governor 0.75KW1.5KW Single-phase motor speed co

isCustomized：Yes Output Current：15A Output Frequency：0-999Hz Weight：1kg Size：145*165*205mm Output Type：triple Output Power：1 - 200KW Type：DC/AC Inverters Origin：Mainland China feature 1：VFD Frequency Translator feature 2：frequency converter feature 3：220V single-phase input single-phase output feature 4：1ph220v-1ph220v feature 5：Constant pressure water supply Input voltage：1ph AC 220V-240V /DC 150V-400V(MPPT) output voltage：1ph AC 0-240V SUSWE320 series inverter is a small general-purpose inverter with multi-function low-noise voltage vector & V/F control, which realizes quick response and precise control of torque, and runs through the inverter for speed regulation. Extremely high control accuracy, automatic tuning of motor parameters, online switching between automatic control and torque control, and torque tracking. Built-in PID controller, simple PLC, 17 kinds of fault monitoring, rich I/O terminals and multiple speed setting methods, which can meet the requirements of various loads for drive control. ■Dual analog input ■Overcurrent, overvoltage, overload, phase loss, short circuit protection ■Simple PLC function ■Built-in PID controller ■Output voltage regulation AVR function ■Built-in EMC filter
