Thermaltake TOUGHFAN 12 PRO High Static Pressure Fan & TOUGHFAN 14 PRO High Static

**TOUGHFAN 12 PRO** P/N CL-F139-PL12BL-A Fan Dimension 120 x 120 x 25 mm Started Voltage 6 V Rated Current 0.19 A Rated Voltage 12 V Power Input 2.28 W Fan Speed PWM 500~2000 R.P.M With L.N.C PWM 500~1500 R.P.M Static Pressure 3.19 mm-H2O With L.N.C 1.72 mm-H2O Air Flow 70.8 CFM With L.N.C 49.13 CFM Noise 22.6 dB-A With L.N.C 18.3 dB-A Bearing Type Hydraulic Bearing Gen.2 Life Expectation 40,000 hrs,25℃ Connector 4 PIN PWM --------------------------------------------------------------- **TOUGHFAN 14 PRO** P/N CL-F140-PL14BL-A Fan Dimension 140 x 140 x 25 mm Started Voltage 6 V Fan Rated Voltage 12 V Rated Current 0.36 A Power Input 4.32 W Fan Speed PWM 500~2000 R.P.M With L.N.C PWM 500~1500 R.P.M Static Pressure 3.57 mm-H2O With L.N.C 2.18 mm-H2O Air Flow 119.6 CFM With L.N.C 87.6 CFM Noise 31.6 dB-A With L.N.C 24.5 dB-A Bearing Type Hydraulic Bearing Gen.2 Life Expectation 40,000 hrs,25℃ Connector 4 PIN PWM --------------------------------------------------------------- Specification Detail FAN DIMENSION 120 x 120 x 25 mm STARTED VOLTAGE 6 V RATED CURRENT 0.19 A RATED VOLTAGE 12 V POWER INPUT 2.28 W FAN SPEED PWM 500~2000 R.P.M With L.N.C PWM 500~1500 R.P.M STATIC PRESSURE 3.19 mm-H2O With L.N.C 1.72 mm-H2O AIR FLOW 70.8 CFM With L.N.C 49.13 CFM NOISE 22.6 dB-A With L.N.C 18.3 dB-A BEARING TYPE Hydraulic Bearing Gen.2 LIFE EXPECTATION 40,000 hrs,25℃ CONNECTOR 4 PIN PWM Thermaltake TOUGHFAN PWM-controlled high static pressure fan features an optimized structure to maximize high-end cooling needs. P/N CL-F117-PL12BL-A FAN DIMENSION 120 x 120 x 25 mm FAN STARTED VOLTAGE 9.0 V FAN RATED VOLTAGE 12 V RATED CURRENT 0.12 A POWER INPUT 1.44 W FAN SPEED 500 ~ 2000 R.P.M With L.N.C PWM 500~1500 R.P.M MAX. STATIC PRESSURE 2. 41mm-H2O MAX AIR FLOW 58.35 CFM NOISE LEVEL 22.3 db-a (without L.N.C) 19.2 db-a (with L.N.C) BEARING TYPE Hydraulic Bearing Gen. 2 LIFE EXPECTATION 40,000 hrs, 25℃ CONNECTOR 4 PIN PWM WEIGHT 212.5 g (Fan*1) ------------------------------------------------------------------- TOUGHFAN 12 Turbo High Static Pressure Radiator Fan (Single Fan Pack) CL-F121-PL12GM-A P/N CL-F121-PL12GM-A FAN DIMENSION 120 x 120 x 25 mm FAN STARTED VOLTAGE 9.0 V FAN RATED VOLTAGE 12 V RATED CURRENT 0.23 A POWER INPUT 2.76 W FAN SPEED PWM 500~2500 R.P.M MAX. STATIC PRESSURE 3.78 mm-H2O MAX AIR FLOW 72.69 CFM NOISE 28.1 dB-A BEARING TYPE Hydraulic Bearing Gen.2 LIFE EXPECTATION 40,000 hrs,25℃ CONNECTOR 4 PIN PWM WEIGHT 217.7 g ---------------------------------------------- TOUGHFAN 14 High Static Pressure Radiator Fan (2 Fan Pack) P/N CL-F085-PL14BL-A FAN DIMENSION 140 x 140 x 25 mm FAN STARTED VOLTAGE 9.0 V FAN RATED VOLTAGE 12 V RATED CURRENT 0.34 A (Fan x1) RATED VOLTAGE 4.08 W (Fan x1) POWER INPUT PWM 500~2000 R.P.M With L.N.C PWM 500~1300 R.P.M MAX. AIR PRESSURE 3.54 mm-H2O MAX AIR FLOW 119.1 CFM NOISE 33.2 dB-A With L.N.C 25.2 dB-A BEARING TYPE Hydraulic Bearing Gen.2 LIFE EXPECTATION 40,000 hrs,25℃ CONNECTOR 4 PIN PWM WEIGHT 240.7 g ---------------------------------------------- TOUGHFAN 14 High Static Pressure Radiator Fan (1 Fan Pack) P/N CL-F118-PL14BL-A FAN DIMENSION 140 x 140 x 25 mm FAN STARTED VOLTAGE 9.0 V FAN RATED VOLTAGE 12 V RATED CURRENT 0.34 A (Fan x1) POWER INPUT 4.08 W (Fan x1) FAN SPEED PWM 500~2000 R.P.M With L.N.C PWM 500~1300 R.P.M MAX. AIR PRESSURE 3.54 mm-H2O MAX AIR FLOW 119.1 CFM NOISE 33.2 dB-A With L.N.C 25.2 dB-A BEARING TYPE Hydraulic Bearing Gen.2 LIFE EXPECTATION 40,000 hrs,25℃ CONNECTOR 4 PIN PWM WEIGHT 240.7 g
