1022-010K-C3-08X : โหลดเซลล์ Capacities 10 kg IP66 Single Point Bending Beam - Vishay Loadcell by pik2pak.com

โหลดเซลล์ Capacities 10 kg IP66 Single Point Bending Beam - Vishay Loadcell by pik2pak.com Model 1022 Tedea-Huntleigh VPGTransducers CeltronㆍRevereㆍSensortronics ㆍTedea-Huntleigh Single-Point Aluminum Load Cell FEATURES Capacities: 3-200 kg Only 22 mm high Aluminum construction Single-point 350 x 350 mm platform IP66 protection OIML R60 and NTEP approved Optional o ATEX, FM and IECEx approvals available o Symmetric configuration available APPLICATIONS Bench scales Counting scales Grocery scales DESCRIPTION The Model 1022 is a low profile single-point load cell designed for direct mounting in low cost weighing platforms. Its small physical size, combined with high accuracy and aluminum construction, makes this low cost load cell ideally suited for retail, bench and counting scales. OUTLINE DIMENSIONS in millimeters* IEC APPROVED Using Model 1022 load cells simplifies scale construction, which results in significant parts and labor savings. The Model 1022 is available in a range of capacities: from 3 to 150 kg, approved to OIML R60 (4000d); to 20 to 150 kg, approved to OIML R60 (6000d); to 3 to 100 kg, approved to NTEP (5000d, single). Environmental protection to IP66 is provided as standard. For hazardous environments, ATEX approved versions are available.
