Type 2 surge protection base element - VAL-MS BE/FM (2817738) [เฉพาะbase ฐานรอง Surge ]

Type 2 surge protection base element - VAL-MS BE/FM (2817738) [เฉพาะbase ฐานรอง Surge ] Base element for type 2 arresters of the VALVETRAB MS series of products, with remote indication contact. Design: 1-channel For installation into a touch protected cabinet. For applications with UC > 500 V distances at the side and distances at the connection area must be minimum of 5 mm between different active parts including earthed parts. IEC test classification: II / T2 EN type: T2 Type: Base element, DIN rail mounting Product type: Base element Product family: VALVETRAB MS Number of positions: 1 Surge protection fault message: Remote indication contact Insulation characteristics Overvoltage category: III Pollution degree : 2 Nominal frequency fN: 50 Hz (60 Hz) Indicator/remote signaling Connection name: Remote fault indicator contact Switching function: Changeover contact Operating voltage: 5 V AC ... 250 V AC / 30 V DC Operating current: 5 mA AC ... 1 A AC / 1 A DC Connection data Connection method: Screw connection Screw thread: M5 Tightening torque: 3 Nm (1.5 mm² ... 16 mm²) 4.5 Nm (25 mm² ... 35 mm²) Stripping length 16 mm: Conductor cross section flexible: 1.5 mm² ... 25 mm² Conductor cross section solid: 1.5 mm² ... 35 mm² Conductor cross section AWG: 15 ... 2 Connection method: Fork-type cable lug Conductor cross section flexible: 1.5 mm² ... 16 mm² Remote fault indicator contact Connection method: Plug-in/screw connection via COMBICON Screw thread: M2 Tightening torque: 0.25 Nm Conductor cross section flexible: 0.14 mm² ... 1.5 mm² Conductor cross section solid: 0.14 mm² ... 1.5 mm² Conductor cross section AWG: 28 ... 16 Protective Circuit Direction of action: 1L-N/PE Nominal frequency fN: 50 Hz (60 Hz) Maximum continuous voltage UC: 600 V AC Rated load current IL: 80 A Short-circuit current rating ISCCR: 25 kA Max. backup fuse with V-type through wiring: 80 A (gG) Max. backup fuse with branch wiring: 125 A (gG) Download datasheet *สินค้ารับประกัน 1ปี *ออกใบกำกับภาษีได้ *เงื่อนไขเป็นไปตามที่บริษัทกำหนด
