CPU AMD RYZEN 7 9800X3D 8 CORE/16 THREAD PROCESSER (100-100001084W0F)

General Specifications Name: AMD Ryzen™ 7 9800X3D Family: Ryzen Series: Ryzen 9000 Series Form Factor: Desktops, Boxed Processor Market Segment: Enthusiast Desktop AMD PRO Technologies: No Consumer Use: Yes Regional Availability: Global Former Codename: Granite Ridge AM5 Launch Date: 11/07/2024 Architecture & Performance Architecture: Zen 5 # of CPU Cores: 8 Multithreading (SMT): Yes # of Threads: 16 Base Clock: 4.7 GHz Max. Boost Clock: Up to 5.2 GHz L1 Cache: 640 KB L2 Cache: 8 MB L3 Cache: 96 MB Processor Technology for CPU Cores: TSMC 4nm FinFET Processor Technology for I/O Die: TSMC 6nm FinFET Package Die Count: 2 Unlocked for Overclocking: Yes Power & Thermal Default TDP: 120W Max. Operating Temperature (Tjmax): 95°C Thermal Solution (PIB): Not Included Recommended Cooler: Liquid cooler recommended for optimal performance Memory & Storage System Memory Type: DDR5 Memory Channels: 2 Max. Memory: 192 GB System Memory Subtype: UDIMM Max Memory Speed: 2x1R: DDR5-5600 2x2R: DDR5-5600 4x1R: DDR5-3600 4x2R: DDR5-3600 ECC Support: Yes (Requires motherboard support) Connectivity Native USB 3.2 Gen 2 (10Gbps) Ports: 4 Native USB 2.0 (480Mbps) Ports: 1 PCI Express® Version: PCIe® 5.0 Native PCIe® Lanes (Total/Usable): 28 / 24 NVMe Support: Boot, RAID0, RAID1, RAID5, RAID10 USB Type-C® DisplayPort™ Alternate Mode: Yes Chipset & Socket Support CPU Socket: AM5 Supporting Chipsets: A620, X670E, X670, B650E, B650, X870E, X870, B840, B850 Boost & Overclocking Technologies CPU Boost Technology: Precision Boost 2 AMD EXPO™ Memory Overclocking Technology: Yes Precision Boost Overdrive: Yes Curve Optimizer Voltage Offsets: Yes AMD Ryzen™ Master Support: Yes Graphics Capabilities Graphics Model: AMD Radeon™ Graphics Graphics Core Count: 2 Graphics Frequency: 2200 MHz Operating System Support OS Support: Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit
