MAINBOARD (เมนบอร์ด) MSI PRO B860-P WIFI (INTEL SOCKET 1851 DDR5 ATX)

model Brand MSI Model B860-P-WIFI CPU Socket 1851 (Arrow Lake) Wattage N/A Chipset Intel B860 Series Core Ultra 5 , Core Ultra 7 , Core Ultra 9 memory Slot 4 Memory Type DDR5 Max. Capacity 256 GB Speed 4800 , 5000 , 5100 , 5200 , 5300 , 5400 , 5500 , 5600 , 5700 , 5800 , 5900 , 6000 , 6100 , 6200 , 6300 , 6400 , 6400 (OC) , 6500 (OC) , 6600 (OC) , 6666 (OC) , 6700 (OC) , 6800 (OC) , 6900 (OC) , 7000 (OC) , 7100 (OC) , 7200 (OC) , 7400 (OC) , 7466 (OC) , 7467 (OC) , 7600 (OC) , 7800 (OC) , 7900 (OC) , 8000 (OC) , 8200 (OC) , 8266 (OC) , 8400 (OC) , 8600 (OC) Graphic & Audio Graphic Integrated Graphics Processor-Intel HD Graphics support: — 1x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz* 1x Type-C DisplayPort Thunderbolt™ 4 port, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. Audio Realtek® ALC897 Codec 7.1-Channel High Definition Audio Storage SATA 2 - Port SATA 3 4 Port RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices M.2 3 Port expansion slots Slot 1 x PCIe 5.0 x16 Slot network LAN Realtek® 8126 5Gbps LAN LAN Speed 10/100/1000M/2.5G/5G Mbps Wireless Intel® Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth® 5.4**, MLO, 4KQAM * 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2. ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2. Back Panel I/O Ports USB 2.0 4 Port USB 3.0 - Port USB 3.1 2 Port Serial - Port USB 3.2 1x Thunderbolt™ 4 40Gbps (Type-C) 2x USB 10Gbps Type-A Port D-Sub (VGA) - Port DVI - Port HDMI 1 Port DisplayPort 1 Port Audio 3 Port PS/2 No Additional No LAN 1 Form Factor Form Factor ATX Power Connector 24 + 8 + 8 + 4 Pin Dimension 24.38 x 30.48 cm warranty การรับประกัน 3 Years
