CCTV 3.6mm HDCVI DAHUA#B2A21P-U-IL-A - A0161549

Brand : DAHUA Model : B2A21P-U-IL Image Sensor : 2MP , CMOS Lens : Lens Type : Fixed-focal Focal Length : 3.6mm Lens Mount : M12 Angle of View : H: 80&deg;; V: 43&deg;; D: 94&deg; Adjustment Angle : Pan : 0&deg;&ndash;360&deg; Tilt : 0&deg;&ndash;90&deg; Rotation : 0&deg;&ndash;360 Shutter : PAL: 1/25 s&ndash;1/100,000 s NTSC: 1/30 s&ndash;1/100,000 s Min. Illumination : 0.02 lux@F2.0 (Color, 30 IRE); 0.002 lux@F2.0 (B/W, 30 IRE) ; 0 lux (Illuminator on) IR : IR : 30m (98.43 ft) Warm light : 20m (65.62 ft) Video Resolution : 1920 (H) &times; 1080 (V) Video Compression : N/A Frame Rate : CVI PAL : 1080p@25 fps NTSC : 1080p@30 fps AHD PAL : 1080p@25 fps NTSC: 1080p@30 fps TVI PAL : 1080p@25 fps NTSC : 1080p@30 fps CVBS PAL: 960H NTSC: 960H Audio : One channel built-in Mic Interface : N/A Functions : Smart Dual Light Broadcast-quality Audio Protection (IP67, Wide Voltage) 4 Signals over 1 Coaxial Cable Long Distance Transmission Simplicity Power : 12 VDC &plusmn; 30% Power Consumption : Max 3.3 W (12 VDC, LED on) Working Environment : Operating Temperature : &ndash;40 &deg;C to +60 &deg;C (&ndash;40 &deg;F to +140 &deg;F) Operating Humidity : <95% (RH), non-condensing Storage Temperature : &ndash;40 &deg;C to +60 &deg;C (&ndash;40 &deg;F to +140 &deg;F) Storage Humidity : <95% (RH), non-condensing Ingress Protection : IP67 Material : Metal Package Contents : N/A Dimension (W x D x H) : 15.00 x 6.97 x 7.00 cm Net Weight : 0.27 Package Dimension (W x D x H) : 0.00 x 0.00 x 0.00 cm Gross Weight : 0.00 Volume : 0.00 ประกัน : 3 ปี
