DVR 16CH. HDTVI HIKVISION#DS-7216HQHI-M1/XT - A0159714

Brand : HIKVISION Model : DS-7216HQHI-M1/XT Supported Camera Types : 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP) Video/Audio input : Video Input : 16CH Analog Camera Input : 16 BNC ports Camera Input : 1. CVI : 5MP(2880 × 1620)@25 fps, 5 MP(2592 × 1944)@20 fps, 4 MP(2560 × 1440)@30 fps, 4MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps 2. TVI : 3K(2960 x 1665)@20 fps, 5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@30 fps, 4MP(2560 × 1440)@25 fps,1080p@30 fps, 1080p@25 fps,720p@30 fps, 720p@25 fps 3. AHD : 5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps 4.CVBS : PAL: 704 × 576, NTSC: 704 × 480 IP Camera Input : 8-ch (up to 24-ch), each up to 4 Mbps ,Up to 6 MP resolution Video Compression : H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 Audio Input : 1-ch (up to 16-ch is optional), RCA (2.0 Vp-p, 1 KΩ) Video/Audio output : HDMI output : 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60H VGA output : 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz Frame rate : Main stream : 3K stream access: 3K lite@12fps;4 MP lite@15fps/1080pLite@20fps;720p/WD1/4CIF/VGA/CIF@20 fsp Sub stream : WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) Audio output : 1-ch, RCA (Linear, 1 KΩ) Two-way Talk : 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) Network : Network Protocol : HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P Remote Connection : 128 Total Bandwidth : 256 Mbps DDNS : Support Hik-Connect & DDNS (Dynamic Domain Name System) Interface : 1x SATA interface, up to 12 TB capacity for each disk 2x (Front panel: 1 × USB 2.0 , Rear panel: 2 × USB 3.0) 1x HDMI 1x VGA 1x 10/100/1000 Mbps Ethernet port, RJ-45) Storage : Up to 12 TB capacity for each disk Power Supply : DC 12V, 3A Power Consumption : ≤ 24 W Working Environment : Operating Temperature : -10 °C to 55 °C (14 °F to 131 °F) Operating Humidity : 10%–90% ONVIF : ONVIF, ISUP PoE : NONE Package Contents : N/A Dimension (W x D x H) : 32.00 x 25.74 x 4.80 cm Net Weight : 2.00 Package Dimension (W x D x H) : 0.00 x 0.00 x 0.00 cm Gross Weight : 0.00 Volume : 0.00 ประกัน : 3 ปี
