CPU ซีพียู AMD RYZEN 7 9800X3D 8CORES/16THREADS AM5

General Specifications • Name : AMD Ryzen™ 7 9800X3D • Series : Ryzen 9000 Series • Form Factor : Desktops , Boxed Processor • Market Segment : Enthusiast Desktop • AMD PRO Technologies : No • Consumer Use : Yes • Regional Availability : Global • Former Codename : Granite Ridge AM5 • Architecture : Zen 5 • # of CPU Cores : 8 • Multithreading (SMT) : Yes • # of Threads : 16 • Max. Boost Clock : Up to 5.2 GHz • Base Clock : 4.7 GHz • L1 Cache : 640 KB • L2 Cache : 8 MB • L3 Cache : 96 MB • Default TDP : 120W • Processor Technology for CPU Cores : TSMC 4nm FinFET • Processor Technology for I/O Die : TSMC 6nm FinFET • Package Die Count : 2 • Unlocked for Overclocking : Yes • AMD EXPO™ Memory Overclocking Technology : Yes • Precision Boost Overdrive : Yes • Curve Optimizer Voltage Offsets : Yes • AMD Ryzen™ Master Support : Yes • CPU Socket : AM5 • Supporting Chipsets : A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850 • CPU Boost Technology : Precision Boost 2 • Instruction Set : x86-64 • Supported Extensions : AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 • Thermal Solution (PIB) : Not Included • Recommended Cooler : Liquid cooler recommended for optimal performance • Max. Operating Temperature (Tjmax) : 95°C • Launch Date : 11/07/2024 • *OS Support : Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit Connectivity • Native USB 3.2 Gen 2 (10Gbps) Ports : 4 • Native USB 2.0 (480Mbps) Ports : 1 • PCI Express® Version : PCIe® 5.0 • Native PCIe® Lanes (Total/Usable) : 28 , 24 • NVMe Support : Boot , RAID0 , RAID1 , RAID5 , RAID10 • System Memory Type : DDR5 • Memory Channels : 2 • Max. Memory : 192 GB • System Memory Subtype : UDIMM • Max Memory Speed : 2x1R DDR5-5600 2x2R DDR5-5600 4x1R DDR5-3600 4x2R DDR5-3600 • ECC Support : Yes (Requires mobo support) Graphics Capabilities • Graphics Model : AMD Radeon™ Graphics • Graphics Core Count : 2 • Graphics Frequency : 2200 MHz • USB Type-C® DisplayPort™ Alternate Mode : Yes Key Features • Supported Technologies : AMD EXPO™ Technology , AMD Ryzen™ Technologies Warranty 3 Years
