Antenna 2.4GHz 3db WiFi Antenna 2.4G Aerial SMA Wireless Router+PCI U.FL IPX to SMA Pigtail Cable For Arduino WIFI, ESP07, ESP32 cam By KPRAppCompile

Antenna 2.4GHz 3db WiFi Antenna 2.4G Aerial SMA Wireless Router+PCI U.FL IPX to SMA Pigtail CableFor Arduino WIFI, ESP07, ESP32 cam By KPRAppCompile Name: 2.4G omnidirectional antenna Frequency band: 2400-2500 Detailed indicators: Electrical Specifications Frequency Range(MHz) 2400-2500 Gain Gain 3dB Standing wave ratio V.S.W.R. <1.5 Polarization Vertical Non-Circularity(dB) ±0.5 Input impedance Impedance(Ω) 50 Lightning Protection Direct Ground Maximum Input Power(W) 50 Mechanical Specifications Connector Type SMA Radiating Element Material Copper Radome Material Radome Material EVA Radome Color Radome Color Gray Antenna size Dimension (mm) 110(Unbend) 92(Bend) Tailing Cable Length(mm) 100/120/200 Packing Size(mm) 295×110×60 Weight Wight(Kg) 0.009/12 Application Condition Indoor Operating Temperature(℃) -40~+70 Reposition Temperature(℃) -55~+80 #antenna, #arduino wifi, #esp07 antenna, #esp32 cam, #wifi 2.4G, #wifi, #antenna wifi
