INTEL CPU ซีพียู CORE I5-14400/14400F LGA 1700

📌 Product Details Model: Intel Core i5-14400F Generation: 14th Gen (Raptor Lake Refresh) Socket: LGA1700 Cores / Threads: 10 Cores (6 Performance-cores + 4 Efficient-cores) / 16 Threads Clock Speed: P-core: 2.5 GHz (Max Turbo up to 4.7 GHz) E-core: 1.8 GHz (Max Turbo up to 3.5 GHz) Cache: L2 = 9.5MB L3 = 20MB Integrated Graphics: None (F-suffix, requires discrete GPU) Memory Support: DDR5-4800 MT/s (Dual Channel) DDR4-3200 MT/s Up to 192GB PCIe Lanes: PCIe 5.0 (16 lanes) + PCIe 4.0 (4 lanes) Power (TDP): Base Power: 65W Maximum Turbo Power: 148W Overclocking: Not supported (non-K series) Warranty: 3 Years ------------------------------------------------------------- Model Core i5 Brand Intel Source : Intel® Core™ i5 processor 14400 specification Socket 1700 (14th Gen - Raptor Lake Refresh) CPU Core / Thread Total Cores : 10 # of Performance-cores : 6 # of Efficient-cores : 4 Total Threads : 16 Frequency Performance-core Base Frequency : 2.5 GHz Efficient-core Base Frequency : 1.8 GHz Turbo Max Turbo Frequency : 4.7 GHz Performance-core Max Turbo Frequency : 4.7 GHz Efficient-core Max Turbo Frequency : 3.5 GHz Integrated Graphics GPU Name : Intel UHD Graphics 730 Graphics Max Dynamic Frequency : 1.55 GHz Graphics Output : eDP 1.4b, DP 1.4a, HDMI 2.1 Execution Units : 24 Max Resolution (HDMI) : 4096 x 2160 @ 60Hz Max Resolution (DP) : 7680 x 4320 @ 60Hz Max Resolution (eDP - Integrated Flat Panel) : 5120 x 3200 @ 120Hz DirectX Support : 12 OpenGL Support : 4.5 OpenCL Support : 3.0 Multi-Format Codec Engines : 1 Intel Quick Sync Video : Yes Intel Clear Video HD Technology : Yes # of Displays Supported : 4 Architecture Intel 7 Cache L2 9.5 MB Cache L3 20 MB TDP 65 W CPU Cooler Yes Warranty 3 Years
