ไดร์เวอร์ LED Driver Vossloh Type ECXe 500.479 No.187116

Order Code : 41002100741 Brand : Vossloh EasyLine DIP switch C-R1 Product features • Compact casing shape Functions • Selectable current output by dip-switch Electrical features • Mains voltage: 220–240 V ±10% • Mains frequency: 50–60 Hz • Push-in terminals: rigid 0.5–1.5 mm² strand 0.75–1.5 mm² • Power factor at full load: > 0.95 • Open circuit voltage (Umax.): 60 V • Secondary side switching of LED modules is not allowed. Safety features • Protection against transient main peaks up to 1 kV (between L and N) • Electronic short-circuit protection • Overload protection • Degree of protection: IP20 • Protection class II • SELV - Nominal output current 150 / 200 / 250 / 300 / 350 / 400 / 450 / 500 mA 6.3 / 8.4 / 10.5 / 12.6 / 14.7 / 16.8 / 18.9 / 21.0 W Applied standards • EN 61347-1 • EN 61347-2-13 • EN 61547 • EN 61000-3-2/EN 61000-3-3 • EN 62384 • EN 55015 • EN 61000-4-2/EN 61000-4-5 Order Code : 41002100741
