ไดแอค DB3 DIAC 36V, 2A, 2-Pin DO-35

ไดแอค DB3 DIAC 36V, 2A, 2-Pin DO-35 The DIAC, or 'diode for alternating current', is a diode that conducts current only after its breakover voltage has been reached momentarily. คุณสมบัติ / Specifications คุณสมบัติ Value Maximum Breakover Current 0.05mA Maximum Breakover Voltage 36V Repetitive Peak On-State Current 2A Repetitive Peak Off-State Current 0.01mA Mounting Type Through Hole Package Type DO-35 Pin Count 2 Dimensions 4.5 x 2 x 2mm Length 4.5mm Width 2mm Maximum Operating Temperature +125 °C Minimum Operating Temperature -40 °C Height 2mm
